Platform Under Bridge Inspection Equipment 8x4 22m Under Bridge Access With Fully Interchangeable Platforms

Platform Under Bridge Inspection Equipment 8x4 22m Under Bridge Access With Fully Interchangeable Platforms
Platform Under Bridge Inspection Equipment 8x4 22m Under Bridge Access With Fully Interchangeable Platforms

Large Image :  Platform Under Bridge Inspection Equipment 8x4 22m Under Bridge Access With Fully Interchangeable Platforms

Product Details:
Place of Origin: Zhejiang.Hangzhou
Brand Name: China Jinggong
Certification: ISO9001, CCC
Model Number: HZZ5320JQJ22
Payment & Shipping Terms:
Minimum Order Quantity: No limited
Price: negotiation
Packaging Details: Naked
Delivery Time: 45days
Payment Terms: L/C,T/T, Western Union
Supply Ability: 2Units/Month
Port of Delivery:: Shanghai / Ningbo
Detailed Product Description
Model: HZZ5320JQJ22 G.V.W.: 32000KG
OUTER DIMENSION: 12420X4000X2500 MAX SPEED: 85KM/H
OPERATING RANGE UNDER BRIDGE(TOTAL): Machanical Hydrostatic Transmission THE MAIN ARM ACROSS WIDTH: 2000~3800mmV
MAX LOAD: 800KG MAX LOAD OF FRONT END: 400KG
VERTICAL OPERATING RANGE UNDER BRIDGE:: 6350mm
High Light:

Low Oil Consumption Bridge Inspection Truck

,

8×4 Driver Bridge Inspection Truck

,

85KM/H Bridge Inspection Truck

Platform under Bridge Inspection Equipment 8x4 , 22m Under Bridge Access with fully-interchangeable platforms
Heavy Duty Bridge Inspection Equipment 8x4 , 22m Under Bridge Access Platforms


Quick Details:

Model:HZZ5320JQJ22
Product name:Platform type Bridge Inspection Vehicle
Chassis Model:VOLVO FM400 8X4
Driver type:8×4
Advantage:low oil consumption, environmental design, ensure high stability



Description:





Bridge Inspection Truck: The operating truck for bridge detection, as its name suggests, is designed to help detect the performance and reliability of a bridge. Reasonable structure, simple operation, more safety design.

The new platform design has imporve much reliability and stability. Much safety for sending the operator into any location of the bridges. The new developed product with it’s own exported chassis and some OEM components, such as US POCLAIN amble motor, US KOHLAR emergency power supply, Germany “HAWE” Mutiple Valve, Italy “WOLFF” valve etc. greatly increase the service life, easy maintenance. Three hydraulic section with broader extension, rotary platform, luffing machanism together created a three-dimensional folding, much more suit for those flyovers, long-span, approach heavy duty bridges.

It is also able to run in extremely worse environments, even on the elevation 2000m, 98% high humidity weather, and 6 Class land wind. The design of the platform with much broader detection range between 12m to 22m and 1.1m width appers more secure working conditions.
Specifications:




TYPEHZZ5320JQJ22
NAMEPlatform type Bridge Inspection Vehicle
CHASSIS TYPEVOLVO FM400 8X4
G.V.W.32000KG
OUTER DIMENSION12420X4000X2500
MAX SPEED85KM/H
HYDRAULIC SYSTEM
SELF-WALK PARTElectro-hydraulic proportional servo system
OPERATING RANGE UNDER BRIDGE(TOTAL)Machanical hydrostatic transmission
MAX. HORIZONTAL RANGE(EFFECTIVE)21000mm
MAX. OVERBRIDGING OF SIDEWALK2000~3800mm
MAX. CROSSING OF SOUND BARRIER3500mm
MAX. LOAD ON PLATFORM800KG
MAX. LOAD ON TELESCOPIC PLATFORM400KG
MAX. LOWERING DEPTH6350mm
THE SINGLE BOOM ACROSS RANGE7M
FIRST SCOPE OF ROTATION0~90°
SECOND SCOPE OF ROTATION0~180°
BALANCER3.5T,5T Movable balancer, fixed balancer
OPERATING RANGE FOR MOVBLE BALANCER950MM
ADDITIONAL STABLER FOR THE REAR AXLEOil cylinder
CONTROL SYSTEMWired/wireless/manual
RESERVE POWERUS kohler generator



Competitive Advantage:


  1. Imported VOLVO Chassis, with 390HP large engine power, Euro IV. Has more merits as: low oil consumption, environmental design, ensure high stability.
  2. Air suspension system can adjust the chasis height automaticly, highly increase the stability for such a pot hole ground.
  3. Hydrostatic drive, highly achieved secure in slope and wet road conditions.
  4. Those hydraulic steering wheel system, greatly balance the widthness while operating.
  5. Two sets of control system on platform either into the control box respectively, allows the operator monitor safety.
  6. The hydraulic synchronous interlock device, intercom system, safty lock valve to ensure the safty handing.
  7. US Kohler emergency power supply, able to achieve the folding reset, in case the engine doesn' attent well.
  8. Max. platform payload is 600kg (can affordable 6-7 operators), the tail of the platform payload is about 250kg. The extendable folding platform can be adjustable luffing from 2-4meter, greatly imporve the inspection area under the bridge.
  9. High strength steel platform frame provide more stability which able to rotate 180°under the bridge, and also keep the limitation of max. drop height for 7meter only.
