3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer

China 3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer supplier
3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer supplier 3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer supplier 3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer supplier 3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer supplier 3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer supplier

Large Image :  3x12T BPW axle 46000L Aluminum Alloy Petroleum Mobile Fuel Tank Trailer

Product Details:

Place of Origin: Zhejiang.Hangzhou
Brand Name: China Jinggong
Certification: ISO9001, CCC
Model Number: HZZ9401GRQ

Payment & Shipping Terms:

Minimum Order Quantity: No limited
Price: negotiation
Packaging Details: Naked
Delivery Time: 45days
Payment Terms: 30% T/T as advanced payment after signed contract, and 70% residual payment paid after buyer’s inspe
Supply Ability: 10 Units/Months
Port of Delivery:: Shanghai/Ningbo
Contact Now
Detailed Product Description
Model: HZZ9401GRQ Certification: ISO9001, CCC
Type: Semi-trailer Material: Stainless Steel
Axle: 3x12T BPW ABS: Haldex
Landing Leg: Jost Tyre: 11.00R22.5 Tubeless Tyre(12pieces)
Dimension: 12500×2500×3712

3x12T BPW axle 46000L (12,150 US Gallon) Aluminum Alloy Tank Semi Trailer for Light Petroleum/Diesel/Gasoline Delivery



Use: Truck Trailer

Type: Semi-Trailer

Material: Stainless steel

Certification: ISO & CCC

Axles: 3x12T BPW

ABS: Haldex

Suspension: Air

Landing Gear: JOST

Kingpin: 50/90#




Specifications:

Name

Standard Configuration

Trailer Chassis

Carbon Steel

Axles

12T BPW axles, with ABS system

Suspension System

Air Suspension

Kingpin

90#

Landing Leg

KIC/JOST

Tyre

11.00R22.5 Tubeless tyre(12pieces)



Overall dimension (mm)

12500×2500×3712

Rated Loading Mass (KG)

40000kgs

Rated Kerb Weight (KG)

7500kgs

Tank material

Aluminum Alloy 5083

Manhole Cover

Aluminium alloy, 20” self-latching manhole cover, with air-van.

Outlet port

Pneumatic sea valve , fix all aluminum alloy connector.

Pump System

Optional

Others

Pipe box, ladder, walkway platform, toolbox,

Fire Extinguisher, electrical system, lightening, mud guard, side fender, etc

accordance by manufacture standard.



The logistic vehicle series mainly included Pressured and Non-pressured Tank Transportation vehicles. Normally for transport the gasoline, light diesel oil, petroleum and other non-corresive fuel properties, rarely impact the damage for other components, widely used in various transportation units, gas stations and other logistic industries.
Material optional for Carbon-steel, Stainless steel, Aluminum alloy


Applications:

  1. Main frame is made of high strength low alloy steel, which can fully enhance its abilities of resistance to torsion, anti-seismic and anti-jolt, and meet the various loading requirements.
  2. The tanker is produced with the special equipments such as automatic welding machine(8m) and CNC plasma cutting and automatic submerged arc welding forming which can realize welding by one side in shape by two sides, having the merits of stable quality, less cost, and good-looking
  3. Sophisticated technique: Main parts of the trailer is processed with advanced equipment. The longitudinal beam is welded by a wholly automatic tracking submerged welding machine; Almost the steel spare parts are treated by shot blast before the assembling, which can greatly increase the adhesion of the paint.
  4. Frame: The frame is manufacture by a structure, which are made of high strength steel. This design reasonably to get a balanced consideration of the intensity, rigidity and toughness, advantages of low tare weight, heavy loading mass, not easy to be distorted.
  5. Axles: The axle can be selected in different famous brand of BPW and SAF, KIC, FUWA ect. domestic and overseas. Also, the ABS system can be optional with Haldex and WABCO etc., can be greatly increase the stability and safety.
  6. Suspension system: Mechanical suspension and air suspension series optional.
  • a. Mechanical suspension series: It used tandem and balance construction, have high strength and strong impacting resistance, evenly distribute the axle load into each axles. High strength material keep the service life much longer and efficient buffering, simple maintenance, easy replacement for the wearing parts.
  • b. Air suspension system: Optional BPW & SAF. More shocking proof which combinated with lifting and steering axles.
  1. Brake system: Much more safety and reliability on dual-loop air brake system.
  2. Air compressor: Displacement can be choosen upto 12cbm/min
