ISUZU Chassis Pneumatic Truck Mounted Attenuator With LED Display Screen

China ISUZU Chassis Pneumatic Truck Mounted Attenuator With LED Display Screen supplier

Large Image :  ISUZU Chassis Pneumatic Truck Mounted Attenuator With LED Display Screen

Product Details:

Place of Origin: Zhejiang.Hangzhou
Brand Name: China Jinggong
Certification: ISO9001, CCC
Model Number: HZZ5060TFZ

Payment & Shipping Terms:

Minimum Order Quantity: No limited
Price: negotiation
Packaging Details: Naked
Delivery Time: 45days
Payment Terms: 30% T/T as advanced payment after signed contract, and 70% residual payment paid after buyer’s inspe
Supply Ability: 8 Units/Months
Contact Now
Detailed Product Description
Color: Yellow Total Weight: 5995kg
Outline Dimension: 6470X2330X3080
High Light:

truck mounted impact attenuator


impact attenuator truck

Attenuator Truck for sale more safety more reliable good performance
Main description:
Attenuator Truck is  a device intended to reduce the damage to structures, vehicles, and motorists resulting from a motor vehicle collision. It is designed to redirect the vehicle away from the hazard or away from roadway machinery and workers. Usually placed in front of fixed structures near highways, such as gore points, crash barrier introductions, or overpass supports.
ISUZU Chassis Pneumatic Truck Mounted Attenuator With LED Display Screen
Attenuator Truck used ISUZU chassis, drive mode is 6 × 4, with a good view cab with air conditioning system and FM / AM radio.
Main characteristic:
1.Reliable Performance
The truck is equipped with special automobile anti-collision buffer vehicle buffer device and large LED display with arrow mobile security features on the automobile chassis, can be used for safety protection of highway, municipal engineering, city road, elevated road and other roads on mobile maintenance, temporary road construction and traffic accident or emergency. The purpose is to protect the construction or rescue personnel, construction equipment free from traffic accidents, to avoid a second accident, can also greatly reduce the vehicle damage.
2.Optimization Chassis
Used FAW or ISUZU chassis, attractive appearance, strong power, huge carrying capacity, good stability, economic environment and the luxurious cab, especially for long-time work.
3.LED Display screen
With a large LED display which can raise and lower. Can rise up about 1.8 meters as a whole. The maximum height of the display screen is about 4.88 meters. The contents of the display can be custom-made, usually showing red or yellow scintillating guide arrow. The display has a WIFI signal input function, and the operator can control arrowhead guidance and text input in the cab.
ISUZU Chassis Pneumatic Truck Mounted Attenuator With LED Display Screen
Main specification for Attenuator Truck:

categoryItem Specification
VehicleProduct modelHZZ5060TFZ
Product standardFZ06JX00
Product nameAttenuator Truck
Outline dimension(L×W×H)6470×2330×3080mm
Kerb weightTotal weight(kg)5670
Front axle(kg)1790
Rear axle(kg)3880
Full load weightTotal weight(kg)5995
Front axle(kg)2115
Rear axle(kg)3880
Max. speed(km/h)100
ChassisChassis modelJX1061TSG2
Rated power/Rotate speed(kw/r.p.m)85/3800
Max. Torque/Rotate speed (Nm/r.p.m)285/1800-2200
Max. Clear power (KW)83
Min. Turning circle diameter(m)≤15
Min. Ground clearance(mm)195
Approach angle(0)27
Departure angle(0)12


Crash prevent buffer device

ManufacturerUSA Lindsay
Model70K(2000kg-70 km/h)
Buffer device total weight(kg)800
Hydraulic pressure11
Buffer device lifting speed (s/journey)10±5

Display screen

ManufacturerHangzhou Wuhu
Size of display screen(L×W)(mm)1920×1600
LED module specificationP10 LED module
Module image resolution32×16
Max. Power consumption(W/㎡)500
Power input(V)AC220
OutputWifi /flat computer
Visible distance(m)≥300
Lifting deviceManufacturerHangzhou Saiqi
Max. Journey(mm)1800
Max. Lifting height(mm)5000
Max. Lifting weight(kg)250
Hydraulic pressure(MPa)11
Container size(mm)2330×2100×450
Lifting light(optional)ManufacturerJiangsu Ouhui
Rated output electric pressure(V)220
Rated output power(W)2000
Light(4PC)Working pressure(V)220
light quantity(lm)4×10000
Lifting barMax. Lifting height(mm)4500
Drive mode
